The high sensitivity TEC SWIR module features a high-performance InGaAs focal plane array (FPA) with an integrated TEC (Thermoelectric Cooling) system. Offering a 640 x 512 resolution with a 15μm pixel pitch, the sensor operates within the 0.9μm to 1.7μm spectral range. The TEC cooling ensures the detector maintains an optimal operating temperature, significantly reducing readout noise. Designed with an integrated, modular architecture, the core is characterized by high sensitivity, a compact form factor, lightweight build, and low power consumption. It supports CameraLink and PAL video interfaces, ensuring seamless integration for end-users.
Specification
|
|
Parameter |
Specifications |
|
Sensor |
Resolution |
640×512 |
|
Pixel Pitch |
15 μm |
|
|
Spectral range |
0.9 μm~1.7 μm |
|
|
Sensor material |
InGaAs |
|
|
Cooling method |
TEC |
|
|
Dynamic range |
65dB(LG),55dB(MG) |
|
|
Readout noise |
500e(LG),60e(MG) |
|
|
Full Well Capacity |
2.2Me(LG),90Ke(MG) |
|
|
Dark current |
30fA @ 0.1V&18℃ |
|
|
Interfaces & video |
Video output |
CameraLink/PAL |
|
Frame rate |
CameraLink：50Hz/25Hz(@640×512) PAL：25Hz(@720×570) |
|
|
Communication |
RS422 |
|
|
Integration time |
Adjustable(auto/manual) |
|
|
Power supply |
DC12V ± 1V,2A |
|
|
Power consumption |
≤6W@25℃(Steady State) |
|
|
Environmental performance |
Operating Temperature |
-40℃~+60℃ |
|
Physical features |
Dimensions (L×W×H) |
≤56mm×56mm×60mm(with C-mount, excl. connectors) |
|
Weight |
≤300g(with C-mount) |
Variable interface available
Cameralink: 200Hz,400Hz,500Hz cameralink digital output modules
Cameralink +PAL: Standard cameralink digital output and analog PAL interface.
SDI+PAL:standard SDI digital output and analog pal interface
In addition to modules, we provide SWIR camera and lens ,SoC board as well:
SWIR Lens system: SWIR-optimized lenses
SWIR camera:Zoom SWIR camera,fixed SWIR camera
| FL | F No. | Spectral Range | FOV(D×H×V) | Detector | Zoom Type |
| 6mm | 1.8 | 0.9-1.7μm | 105°×93.6° × 77° | 640*512,15um | Manual |
| 12mm | 1.4 | 0.9-1.7μm | 66.5°×55.2°×42.6° | 640*512,15um | Manual |
| 16mm | 1.4 | 0.9-1.7μm | 53.6°×43.4°×33.2° | 640*512,15um | Manual |
| 25mm | 1.4 | 0.9-1.7μm | 36°×28.7°×21.8° | 640*512,15um | Manual |
| 35mm | 1.4 | 0.9-1.7μm | 26°×21°×15.7° | 640*512,15um | Manual |
| 50mm | 1.4 | 0.9-1.7μm | 17.2°×14°×10.5° | 640*512,15um | Manual |
| 100mm | 2.0 | 0.9-1.7μm | 9.3°×7.3°×5.4° | 640*512,15um | Manual |
| 500mm | 7.0 | 0.4~2.5μm | 1.1° ×0.8° | 640*512,15um | Manual |
| 40~320mm | 2.2 | 0.9-1.7μm | 9.15°×7.32/3.67°×2.93 | 640*512,15um | motorized |
| 88~1200mm | 2.8-3.2 | 09-1.7μm | 21.74°×17.47°-1.83°×1.47 | 640*512,15μm | motorized |
Application
